產品展示
PRODUCT
結構合理、風葉強度高
噪音低、效率高
適用于排送高溫氣體及其他含油、含水、塵埃氣體
適用于排送不含易燃、易爆、腐蝕性及溫度不超過80°C的氣體，耐高溫120℃
氣體塵量要求不超過150mg/m3
Reasonable structure with high intensity blade
Low noise,high efficiency
Suitable to transmit the air with the temperature below 80°C in the
environment where has not flammable,explosive and caustic air,High temperature resistance of 120 ℃
the dust containing index is below 150mg/m3
產品詳情
|
型號
Model |
電壓
Voltage |
功率
Power |
轉速
Revolution |
風量
Air Volume |
風壓 Wind pressure （Pa） |
規(guī)格
Specifications |
總重量
Total weight |
葉輪重量 Wind wheel Weight (Kg) |
C式單價 Type C unit price (Yuan) |
軸承座價 Price of bearing seat （RMB） |
|
KT4C-2 |
380 |
1.5 |
2800 |
8370 |
220 |
480×470×710 |
45 |
1.9 |
2200 |
280 |
|
KT5C-2 |
380 |
3 |
2800 |
10728 |
260 |
500×580×850 |
56 |
3 |
3160 |
280 |
|
KT5C-4 |
220 |
1.5 |
1450 |
6540 |
145 |
500×580×850 |
50 |
3 |
2800 |
340 |
|
380 |
||||||||||
|
KT6C-2 |
380 |
5.5 |
2800 |
17650 |
363 |
500×670×985 |
78 |
5.9 |
5800 |
540 |
|
KT6C-4 |
380 |
2.2 |
1450 |
14000 |
190 |
500×670×98 |
63 |
5.9 |
3400 |
500 |
|
KT7C |
380 |
3 |
1450 |
19800 |
210 |
610x770x1070 |
99.3 |
6.4 |
4200 |
700 |
|
KT8C |
380 |
4 |
1450 |
28350 |
230 |
610X870X1170 |
124 |
7.1 |
5200 |
700 |
|
KT9C |
380 |
5.5 |
960 |
36455 |
270 |
700X970X1360 |
130 |
9.8 |
7400 |
800 |
|
KT10C |
380 |
7.5 |
960 |
42680 |
295 |
710x1080x1400 |
150 |
11.8 |
8000 |
100 |
